P0022 Fault Code

P0022 OBD-II Trouble Code Short Description

A Camshaft Position - Timing Over-Retarded (Bank 2)

What does trouble code P0022 mean?

The P0022 fault code is a generic OBD-II diagnostic code that indicates a problem with the A Camshaft Position - Timing Over-Retarded on Bank 2. This means that the camshaft on bank 2, which is the side of the engine opposite to the cylinder number one, is not in sync with the crankshaft position.

The engine control module (ECM) uses the camshaft position sensor signals to determine the position of the camshaft and ensure proper timing of the engine's valves. If the ECM detects that the camshaft is over-retarded, meaning it is not in the correct position or timing, the P0022 code is set.

There are several potential causes for this fault code, including:

  1. Faulty camshaft position sensor: A malfunctioning sensor can provide inaccurate readings to the ECM, leading to incorrect camshaft timing.

  2. Timing chain or belt issue: A worn or stretched timing chain or belt can cause slack, resulting in the camshaft not being properly timed.

  3. Oil flow issues: Insufficient oil pressure or restricted oil flow to the variable valve timing system can cause timing problems.

  4. ECM software update: In some cases, a software update may be required to address ECM programming issues related to camshaft timing.

To diagnose and resolve the P0022 code, a qualified mechanic will typically perform the following steps:

  1. Inspect the camshaft position sensor and wiring for any damage or connectivity issues. Replace the sensor if necessary.

  2. Verify proper tension and condition of the timing chain or belt. Replace if worn or stretched.

  3. Check the engine oil level and condition. Ensure proper oil viscosity is being used and there are no clogs or restrictions in the oil passages.

  4. Perform a software update on the ECM if applicable.

Once the underlying issue is addressed, the mechanic will clear the fault code from the ECM and test the vehicle to ensure that the camshaft timing is now within the specified range.

It is important to rectify the P0022 fault code promptly as it can affect engine performance, fuel economy, and potentially cause damage if left unresolved.


What are the symptoms of the P0022 code?

The P0022 fault code indicates a problem with the A Camshaft Position Timing Over-Retarded on Bank 2. Some common symptoms associated with this code include:

  • Check Engine Light (CEL) illuminated
  • Engine misfires or runs rough
  • Decreased fuel efficiency
  • Poor acceleration or lack of power
  • Engine stalling or difficulties in starting

It is important to note that these symptoms may vary depending on the specific make and model of the vehicle. If you are experiencing any of these issues, it is recommended to have your vehicle diagnosed and repaired by a qualified mechanic.


What causes the P0022 code?

The P0022 fault code indicates a problem with the camshaft position timing being over-retarded on Bank 2. This fault code is commonly seen in vehicles with variable valve timing (VVT) systems. Here are some potential causes of the P0022 fault code:

  1. Faulty camshaft timing solenoid - The camshaft timing solenoid controls the timing of the camshaft. If it malfunctions or fails, it can cause the timing to be over-retarded, triggering the P0022 code.

  2. Debris or sludge buildup - Over time, dirt, debris, or sludge can accumulate in the VVT system, affecting the operation of the camshaft timing components and leading to timing issues.

  3. Engine oil issues - Low oil level, degraded oil quality, or a clogged oil passage can interfere with the proper functioning of the VVT system, resulting in a P0022 code.

  4. Faulty camshaft position sensor - A malfunctioning camshaft position sensor may provide incorrect signals to the engine control module (ECM), causing the timing to be excessively retarded and triggering the fault code.

  5. Timing chain or belt issues - If the timing chain or belt is worn, stretched, or improperly installed, it can cause the camshaft timing to be off, resulting in the P0022 fault code.

  6. ECM software issue - In rare cases, a programming or software issue with the ECM can cause the camshaft timing to be over-retarded, leading to the P0022 code.

It is important to note that these are general potential causes, and for accurate diagnosis and repair, it is recommended to consult a qualified mechanic or use a diagnostic tool to pinpoint the specific issue causing the P0022 fault code on a particular vehicle.

Possible Solutions

How to fix P0022?

To fix the P0022 fault code on cars, follow these steps:

  1. Check the oil level and condition: Ensure that the engine has enough clean oil. If the oil is dirty or low, change it.
  2. Inspect the wiring: Check the wiring for any damage, loose connections, or corrosion. Repair or replace as necessary.
  3. Examine the camshaft sensor: Inspect the camshaft position sensor for any faults. Clean or replace it if needed.
  4. Check the timing belt or chain: Verify that the timing belt or chain is properly aligned and not loose or worn out. Adjust or replace if necessary.
  5. Inspect the timing solenoid valve: Check the solenoid valve for any clogs or malfunctions. Clean or replace it as needed.
  6. Perform an engine relearn procedure: Use a professional diagnostic tool to perform an engine relearn procedure, which resets the engine's timing and camshaft positions.
  7. Consult a professional: If the above steps do not resolve the issue, it is recommended to consult a professional mechanic or dealership for further diagnosis and repair.

Please note that these steps are for informational purposes only and may not be suitable for all car models. It is always best to refer to the specific vehicle's repair manual or consult with a qualified mechanic for accurate guidance.
