P0274 Fault Code

P0274 OBD-II Trouble Code Short Description

Cylinder #5 Injector Circuit High

What does trouble code P0274 mean?

Error code P0274 refers to a problem in the injector circuit of cylinder #5. This code is specific to vehicles with a multi-point fuel injection system, which includes most modern gasoline engines.

When the engine control module (ECM) detects that the voltage in the injector circuit of cylinder #5 is higher than the manufacturer's specified limits, it triggers the P0274 error code. This can happen due to various issues, such as a faulty injector, a wiring problem, or a problem with the ECM itself.

Having a high voltage in the injector circuit can lead to several problems. It may cause the injector to deliver more fuel than necessary, resulting in an excessively rich fuel mixture. This can lead to poor fuel economy, engine misfires, and increased emissions. In severe cases, it can even damage the catalytic converter.

To diagnose and solve this issue, the following steps may be taken:

  1. Inspection: The wiring and connectors related to the injector circuit of cylinder #5 should be thoroughly inspected for any signs of damage or corrosion. Any issues found should be repaired or replaced as necessary.

  2. Injector testing: The injector for cylinder #5 should be tested to ensure that it is functioning properly. This can be done using specialized diagnostic equipment. If the injector is found to be faulty, it will need to be replaced.

  3. ECM scan: The ECM should be scanned for any additional error codes or diagnostic trouble codes (DTCs) that may provide further insight into the underlying problem. If any other issues are found, they should be addressed accordingly.

  4. Repair or replacement: Depending on the findings of the diagnosis, the necessary repairs or replacements should be carried out. This may involve repairing damaged wiring, replacing a faulty injector, or even replacing the ECM if necessary.

Overall, addressing the P0274 error code promptly is important to prevent further damage to the engine and ensure proper fuel delivery. It is recommended to seek the assistance of a professional mechanic or technician who has the necessary tools and expertise to diagnose and fix the issue accurately.


What are the symptoms of the P0274 code?

The P0274 fault code refers to a problem with the cylinder #5 injector circuit being too high. Symptoms of this fault code may include:

  • Engine misfire: You may notice a rough or uneven running engine, particularly when accelerating or at idle.

  • Loss of power: The vehicle may experience a decrease in power, making it difficult to accelerate or maintain higher speeds.

  • Poor fuel efficiency: Due to the improper fuel injection from cylinder #5, the engine may consume more fuel than usual, leading to reduced fuel efficiency.

  • Check Engine Light: The P0274 fault code will trigger the Check Engine Light to illuminate on the dashboard. This serves as a warning for the issue at hand.

If you are experiencing any of these symptoms, it is recommended to have the vehicle diagnosed and repaired by a qualified mechanic to address the cylinder #5 injector circuit high issue.


What causes the P0274 code?

The P0274 fault code is specific to the injector circuit for Cylinder #5 in a vehicle. This code indicates that there is a high voltage or resistance issue detected in the fuel injector circuit for Cylinder #5. Some possible causes of this fault code are:

  1. Faulty fuel injector: The fuel injector for Cylinder #5 may be malfunctioning, causing a high voltage or resistance issue.

  2. Wiring or connection problem: There may be a problem with the wiring or connection between the fuel injector and the engine control module (ECM), leading to a high voltage or resistance reading.

  3. ECM malfunction: The ECM, which controls the fuel injectors, may be faulty or not functioning properly, resulting in a high voltage or resistance issue for the Cylinder #5 injector circuit.

  4. Fuel delivery issue: A problem with fuel delivery, such as a clogged fuel line or a faulty fuel pressure regulator, can cause a high voltage or resistance problem in the injector circuit.

  5. Other electrical issues: Other electrical problems in the vehicle, such as a short circuit or a damaged wire in the injector circuit, can also trigger the P0274 fault code.

To diagnose and resolve the P0274 fault code, it is recommended to take the vehicle to a qualified mechanic or dealership. They will use a scan tool to read the fault code and perform further testing to identify the exact cause of the issue. Once the cause is determined, the necessary repairs or replacements can be made to resolve the fault code and restore proper injector operation.

Possible Solutions

How to fix P0274?

To fix the P0274 fault code, which indicates a high circuit condition in the injector of cylinder #5, you can follow these steps:

  1. Check the injector wiring: Inspect the wiring harness connected to the cylinder #5 injector. Look for any signs of damage, such as frayed wires or loose connections. Repair or replace any faulty wiring.

  2. Check the injector connector: Ensure that the injector connector is securely attached and making a good connection. Clean any dirt or corrosion from the connector terminals.

  3. Test the injector resistance: Use a multimeter to measure the resistance of the cylinder #5 injector. Compare the reading to the manufacturer's specifications. If the resistance is too high, replace the injector.

  4. Inspect the injector for clogs: Remove the injector from the engine and visually inspect it for any obstructions or clogs. Clean or replace the injector if necessary.

  5. Verify the injector pulse signal: Use a noid light or an oscilloscope to check if the injector is receiving a proper pulse signal. If there is no signal or an intermittent signal, further diagnosis may be required to determine the cause.

  6. Check the fuel pressure and delivery: Low fuel pressure or a restricted fuel line can cause injector circuit issues. Test the fuel pressure and ensure that it meets the manufacturer's specifications.

  7. Perform a compression test: A low compression in cylinder #5 can affect injector performance. Conduct a compression test to determine if there are any issues with the cylinder's compression.

  8. Clear the fault codes: After completing the repairs, clear the fault codes using an OBD-II scanner. If the code returns, further diagnosis may be needed to identify the root cause of the issue.

It is recommended to consult a professional mechanic or refer to the vehicle's service manual for specific instructions and diagnostic procedures related to your car model.
